Fujifilm XF 8-16mm F2.8 R LM WR X Mount Review

Fujifilm XF 8-16mm F2.8 R LM WR

Main Features

  • 8-16mm Focal Range
  • F2.8 Max Aperture
  • Weather-sealed
  • Max Format: APS-C / DX
  • Fujifilm X Mount
  • Weight: 805g / 1.77 lb
  • Dimensions(øxL): 88mm x 122mm
  • Min Focus Distance: 0.25m
  • Max Magnification: 0.1x
CHECK PRICE
CHECK PRICE
Compare To
x
Add a Lens for comparison

Fujifilm XF 8-16mm F2.8 R LM WR Overview


Fujifilm XF 8-16mm F2.8 R LM WR is a Fixed aperture Auto Focus (AF) Ultra-Wideangle Zoom lens with APS-C / DX max sensor coverage, and it is designed to be used with X Mount cameras.

What type of photography is the Fujifilm XF 8-16mm F2.8 R LM WR lens good for?

The type of photography that you are planning to use the Fujifilm XF 8-16mm F2.8 R LM WR is an important decision factor. Here we have evaluated its suitability to various photography scenarios:

Photography Type Suitability
Bird/WildlifePoor
SportsPoor
PortraitFair
TravelAverage
StreetAverage
WeddingFair
Walk AroundAverage
VloggingGood
LandscapeVery Good
MacroPoor

Fujifilm XF 8-16mm F2.8 R LM WR is a member of Fujifilm's XF F2.8 Zoom series of lenses. Below you can see the latest lenses in this series.

XF F2.8 Zoom Series Lenses in Fujifilm X Mount
Model Coverage Weight Focusing Street Price
Fujifilm XF 8-16mm F2.8 R LM WR Lens Fujifilm XF 8-16mm F2.8 R LM WR
APS-C / DX 805gr AF Amazon B&H Photo
Fujifilm XF 50-140mm F2.8 R LM OIS WR Lens Fujifilm XF 50-140mm F2.8 R LM OIS WR
Compare
APS-C / DX 995gr AF Amazon B&H Photo
Fujifilm XF 16-55mm F2.8 R LM WR Lens Fujifilm XF 16-55mm F2.8 R LM WR
Compare
APS-C / DX 655gr AF Amazon B&H Photo

Reasons to Buy Fujifilm XF 8-16mm F2.8 R LM WR Lens

Here we've included a summary of the advantages and disadvantages of the Fujifilm XF 8-16mm F2.8 R LM WR lens in a list form to help you determine whether it offers the features you need.

PROs
Weather-sealed
Autofocus
Aperture Ring
Hood supplied
Full-time Manual Focusing
Fast Aperture at Wide end
Fast Aperture at Tele end
Constant f2.8 aperture throughout the range
9 Diaphragm Blades for Smooth Bokeh
Extreme Wide-angle capability
Minimum focus distance of 0.25m / 9.8 inch
Report a correction

Buy Fujifilm XF 8-16mm F2.8 R LM WR from Amazon or B&H PHOTO


CONs
Lens Extents while zooming
Pricey


Lens Mount

Fujifilm XF 8-16mm F2.8 R LM WR is compatible with cameras that have a Fujifilm X lens mount. Some of the latest released cameras that are compatible with the Fujifilm X lenses are Fujifilm X-S20, Fujifilm X-T5 and Fujifilm X-H2.

Fujifilm X-S20 with Fujifilm XF 8-16mm F2.8 R LM WR Lens Size
Fujifilm X-S20 with the Fujifilm XF 8-16mm F2.8 R LM WR Lens
Fujifilm X-T5 with Fujifilm XF 8-16mm F2.8 R LM WR Lens Size
Fujifilm X-T5 with the Fujifilm XF 8-16mm F2.8 R LM WR Lens
Fujifilm X-H2 with Fujifilm XF 8-16mm F2.8 R LM WR Lens Size
Fujifilm X-H2 with the Fujifilm XF 8-16mm F2.8 R LM WR Lens

Size, Weight and Filter Thread

Size and weight is a very important decision factor when searching for your next lens. Fujifilm XF 8-16mm F2.8 R LM WR has a maximum diameter of 88mm and total length of 122mm when not extended. It weighs 805g / 28.4 oz.

Below you can find a scaled side-by-side image of Fujifilm XF 8-16mm F2.8 R LM WR and Fujifilm XF 10-24mm F4 R WR (Fujifilm X mount) to get a better idea of how their sizes compare in real life. Check the detailed comparison of these two lenses here.

Fujifilm XF 8-16mm F2.8 R LM WR vs Fujifilm XF 10-24mm F4 R WR Lens Size Comparison
Comparison image of the Fujifilm XF 8-16mm F2.8 R LM WR and the Fujifilm XF 10-24mm F4 R WR Size and Weight


https://cameradecision.com/lenses/img/other/Fujifilm-XF-8-16mm-F2.8-R-LM-WR-topview.jpg
Fujifilm XF 8-16mm F2.8 R LM WR Lens Top View




Focal Range

Fujifilm XF 8-16mm F2.8 R LM WR has a focal range of 8-16mm and 2.0X zoom ratio which has a 35mm equivalent focal range of 12-24mm when used on a APS-C / DX format camera.



Weather Sealings

The Fujifilm XF 8-16mm F2.8 R LM WR is a weather-sealed lens, which provides extra protection to prevent water and dust get inside the lens and camera body under light rain, snow and wind. In order to have effective protection, you have to pair the Fujifilm XF 8-16mm F2.8 R LM WR with a weather-sealed camera body such as the Fujifilm X-T5, Fujifilm X-H2 and Fujifilm X-H2S.

Zoom Method

Fujifilm XF 8-16mm F2.8 R LM WR features Rotary (extending) zoom method where the length of the lens changes as you zoom in or out. This makes it possible to design the lens with a smaller minimum length ( generally when it is zoomed out) compared to internal zoom lenses. The disadvantages of this design are being harder to seal against dust and moisture, weight balance shifting while zooming and zoom creep in certain lenses.

Maximum Magnification Ratio

Fujifilm XF 8-16mm F2.8 R LM WR has a Max Magnification Ratio of 0.1x and has a minimum focusing distance of 0.25m. 0.1x means that the max magnification ratio is very low and not suitable even for modest close-up shots.

Below are the 3 Ultra-Wideangle Zoom type Fujifilm X mount lens alternatives with highest max magnification ratios:

  • Tamron 11-20mm F2.8 Di III-A: 0.25x - (Compare)
  • Fujifilm XF 10-24mm F4 R WR: 0.16x - (Compare)
  • Fujifilm XF 10-24mm F4 R: 0.16x - (Compare)

Aperture

Fujifilm XF 8-16mm F2.8 R LM WR is a fixed aperture lens with a constant max aperture of f2.8 from 8mm all the way to the 16mm .

Focal Length Max Aperture Min Aperture
8mm F2.8 F22
16mm F2.8 F22

Optical Formula

Fujifilm XF 8-16mm F2.8 R LM WR's optical formula consists of 20 elements in 13 groups . Following special elements are used in this design:

  • 4 aspherical
  • 3 ED
  • 3 Super ED elements
  • Nano GI coating

Lens Hood

Fujifilm XF 8-16mm F2.8 R LM WR comes with a removable lens hood which is handy to reduce lens flare and glare in your photos.

Body Colour

Fujifilm XF 8-16mm F2.8 R LM WR is available in Black color.

https://cameradecision.com/lenses/img/other/Fujifilm-XF-8-16mm-F2.8-R-LM-WR-withcamera.jpg
Fujifilm XF 8-16mm F2.8 R LM WR Attached to a camera

Popular Comparisons of Fujifilm XF 8-16mm F2.8 R LM WR

Here are the eight most popular comparisons of the Fujifilm XF 8-16mm F2.8 R LM WR amongst Camera Decision readers.

Top Alternatives of Fujifilm XF 8-16mm F2.8 R LM WR Lens
Model Coverage Weight Focusing Street Price
Fujifilm XF 10-24mm F4 R OIS WR Lens Fujifilm XF 10-24mm F4 R OIS WR
Compare
APS-C / DX 385 g / 0.85 lb AF Amazon B&H Photo
Fujifilm XF 8mm F3.5 R WR Lens Fujifilm XF 8mm F3.5 R WR
Compare
APS-C / DX 215 g / 0.47 lb AF Amazon B&H Photo
Fujifilm XF 10-24mm F4 R OIS Lens Fujifilm XF 10-24mm F4 R OIS
Compare
APS-C / DX 410 g / 0.90 lb AF Amazon B&H Photo
Tamron 11-20mm F2.8 Di III-A RXD Lens Tamron 11-20mm F2.8 Di III-A RXD
Compare
APS-C / DX 335 g / 0.74 lb AF Amazon B&H Photo
Fujifilm XF 16-55mm F2.8 R LM WR Lens Fujifilm XF 16-55mm F2.8 R LM WR
Compare
APS-C / DX 655 g / 1.44 lb AF Amazon B&H Photo
Fujifilm XF 16-80mm F4 R OIS WR Lens Fujifilm XF 16-80mm F4 R OIS WR
Compare
APS-C / DX 440 g / 0.97 lb AF Amazon B&H Photo
Fujifilm XF 16mm F1.4 R WR Lens Fujifilm XF 16mm F1.4 R WR
Compare
APS-C / DX 375 g / 0.83 lb AF Amazon B&H Photo
Fujifilm GF 20-35mm F4 R WR Lens Fujifilm GF 20-35mm F4 R WR
Compare
Medium Format 725 g / 1.60 lb AF Amazon B&H Photo


**This post contains affiliate links, and I will be compensated if you make a purchase after clicking through my links. As an Amazon Associate, I earn from qualifying purchases.

Fujifilm XF 8-16mm F2.8 R LM WR Alternatives in Fujifilm X Mount
Model Coverage Weight Focusing Street Price
Tamron 11-20mm F2.8 Di III-A RXD Lens Tamron 11-20mm F2.8 Di III-A RXD
Compare
APS-C / DX 335 g / 0.74 lb AF Amazon B&H Photo

Related Blog Posts

Nikon Z Mount Lens Roadmap Updated, One More f1.2 Lens to Come
Nikon Zf Size with 30 different Z-Mount Lenses Attached: Most Compact to Largest
Nikon 135mm F1.8 Plena vs 58mm F0.95 Noct Lens Sizes Comparison
Nikon Z 135mm F1.8 S Plena vs Canon RF 135mm F1.8 L IS USM vs Sony FE 135mm F1.8 GM Lenses Size And Feature Comparison
A 500mm F6.3 Full frame lens for only $329?
Tamron 17-50mm f/4 Di III VXD Lens Available for Pre-Order. And Yes, It is a Full-frame Lens
Fujifilm GF 110mm F5.6 T/S, 30mm F5.6 T/S and 55mm F1.7 Lenses: Medium Format comes with a Price tag
Panasonic Releases Updated 100-400mm and 35-100mm Lenses for MFT Cameras

Fujifilm XF 8-16mm F2.8 R LM WR Detailed Specifications


General
Brand Fujifilm
Lens Type Zoom
Lens Type Wideangle Zoom
Lens Mount Fujifilm X
Max Format APS-C / DX
Focal Range 8-16mm
Image Stabilization
Colour Black
Zoom Method Rotary (extending)
Power Zoom No
Zoom Lock No
Zoom Ratio 2.0X
APERTURE
Max Aperture F2.8
Min Aperture F22
Aperture Ring Yes
Diaphragm Blades 9
Optics
Optical Elements 20
Optical Groups 13
Special Elements 4 aspherical + 3 ED + 3 Super ED elements, Nano GI coating

FOCUSING
Min Focus Distance 0.25m
Max Magnification 0.1X
Autofocus Yes
AF Motor Type Linear Motor
Full Time Manual Yes
Focus Method Internal
Distance Scale No
DoF Scale No
PHYSICAL SPECS
Weight 805g
Diameter 88mm
Length 122mm
Materials Magnesium alloy
Weather Sealing Yes
Filter Thread Unknown
Filter Notes -
Hood Supplied Yes
Tripod Collar No
Report a Correction
Frequently Asked Questions about Fujifilm XF 8-16mm F2.8 R LM WR
is the Fujifilm XF 8-16mm F2.8 R LM WR a Weather-sealed lens?
What is the Minimum Focusing Distance of Fujifilm XF 8-16mm F2.8 R LM WR
is the Fujifilm XF 8-16mm F2.8 R LM WR an Autofocus (AF) lens?
What is the Filter Thread Size of Fujifilm XF 8-16mm F2.8 R LM WR
Does Fujifilm XF 8-16mm F2.8 R LM WR have Image Stabilization?
Does Fujifilm XF 8-16mm F2.8 R LM WR have Aperture Ring?
What is the Maximum Magnification Ratio of Fujifilm XF 8-16mm F2.8 R LM WR
