Panasonic GH5 II has a
20.0MP Four Thirds (17.3 x 13 mm ) sized CMOS sensor and features Venus Engine processor. On the other hand, Panasonic GH2 has a
16.0MP Four Thirds (17.3 x 13 mm ) sized CMOS sensor and features Venus Engine FHD processor.
Another difference between these two cameras is that Panasonic GH5 II's sensor lacks anti-alias (Low-Pass) filter. Removing anti-alias filter increases the sharpness and level of detail but at the same time, it increases the chance of moiré occurring in certain scenes.
Below you can see the GH5 II and GH2 sensor size comparison.
Panasonic GH5 II and Panasonic GH2 have the same sensor sizes so they will provide same level of control over the depth of field when used with same focal length and aperture. On the other hand, since Panasonic GH2 has 26% larger pixel area (14.12µm2 vs 11.16µm2) compared to Panasonic GH5 II, it has larger pixel area to collect light hence potential to have less noise in low light / High ISO images.
DxOMark Sensor Scores
Both Panasonic GH5 II and Panasonic GH2 sensors have been tested by DxoMark. DxoMark scores camera sensors for color depth (DXO Portrait), dynamic range (DXO Landscape) and low-light sensitivity (DXO Sports), and also gives them an overall score. Of the two cameras that we are comparing, GH5 II has scored 79, 19 points higher than GH2.
Model |
Overall |
Color Depth |
Dynamic Range |
Low-light ISO |
Panasonic GH5 II |
79 |
23.7 bits |
13.1 Evs |
1136 ISO |
Panasonic GH2 |
60 |
21.2 bits |
11.3 Evs |
655 ISO |
