Olympus E-PL2 has a
12.0MP Four Thirds (17.3 x 13 mm ) sized CMOS sensor and features Truepic V processor. On the other hand, Panasonic GF6 has a
16.0MP Four Thirds (17.3 x 13 mm ) sized CMOS sensor and features Venus Engine FHD processor.
Below you can see the E-PL2 and GF6 sensor size comparison.
Sensor Size and Resolution Comparison image of Olympus E-PL2 and Panasonic GF6 Cameras
Olympus E-PL2 and Panasonic GF6 have the same sensor sizes so they will provide same level of control over the depth of field when used with same focal length and aperture. On the other hand, since Olympus E-PL2 has 29% larger pixel area compared to Panasonic GF6, it has potential to collect more light on pixel level hence have less noise in low light / High ISO images.
DxOMark Sensor Scores
Both Olympus E-PL2 and Panasonic GF6 sensors have been tested by DxoMark. DxoMark scores camera sensors for color depth (DXO Portrait), dynamic range (DXO Landscape) and low-light sensitivity (DXO Sports), and also gives them an overall score. Of the two cameras that we are comparing, E-PL2 has scored 55, 1 points higher than GF6.
Model
Overall
Color Depth
Dynamic Range
Low-light ISO
Olympus E-PL2
55
21.4 bits
10.2 Evs
573 ISO
Panasonic GF6
54
20.7 bits
10.6 Evs
622 ISO
Sensor size sets the circle of confusion, so it drives how much depth of field each
of these bodies gives you at a given aperture. You can calculate it exactly for the
Olympus E-PL2
or the
Panasonic GF6 ,
including hyperfocal distance.
