Samsung NX30 has a
20.0MP APS-C (23.5 x 15.7 mm ) sized CMOS sensor and features DRIMeIV processor. On the other hand, Samsung NX1 has a
28.0MP APS-C (23.5 x 15.7 mm ) sized BSI-CMOS sensor and features DRIMe 5 processor.
Samsung NX1's sensor provides 8MP more than Samsung NX30's sensor, which gives a significant advantage in real life. You can print your images larger or crop more freely.
On the other hand, please keep in mind that Max sensor resolution is not the only determinant of resolving power. Factors such as the optical elements, low pass filter, pixel size and sensor technology also affects the final resolution of the captured image.
One other difference between these two cameras that is worth mentioning is that Samsung NX1's sensor doesn't have an anti-alias (Low-Pass) filter. Removing anti-alias filter increases the sharpness and level of detail but at the same time, it increases the chance of moiré occurring in certain scenes.
Below you can see the NX30 and NX1 sensor size comparison.
Samsung NX30 and Samsung NX1 have the same sensor sizes so they will provide same level of control over the depth of field when used with same focal length and aperture. On the other hand, since Samsung NX30 has 40% larger pixel area compared to Samsung NX1, it has potential to collect more light on pixel level hence have less noise in low light / High ISO images.
DxOMark Sensor Scores
DxOMark is a benchmark that scientifically assesses image quality of camera sensors. It scores camera sensors for color depth (DXO Portrait), dynamic range (DXO Landscape) and low-light sensitivity (DXO Sports), and also gives them an overall score. Samsung NX30 and Samsung NX1 sensors have been tested by DxO and the results show that NX1 has a better overall score of 83, 6 points higher compared to NX30's score of 77.
Model |
Overall |
Color Depth |
Dynamic Range |
Low-light ISO |
Samsung NX30 |
77 |
23.5 bits |
12.4 Evs |
1014 ISO |
Samsung NX1 |
83 |
24.2 bits |
13.2 Evs |
1363 ISO |
